Подробная информация о продукте:
|
| Материал: | Безопасность напряжения тока Ac керамическая | Тип пакета: | Через отверстие, большая часть |
|---|---|---|---|
| Температурная характеристика: | Y5U | Емкость: | 470PF |
| Расклассифицированное напряжение тока:: | 400VAC | Рабочая температура: | -25 ~125℃ |
| Допуск емкости: | ± 10% | Дистанционирование руководства (mm): | 10 |
| Высокий свет: | Стабилизированный керамический конденсатор 470pf,Водоустойчивый керамический конденсатор 470pf,Многофункциональные конденсаторы безопасности AC |
||
Конденсатор Y1 -471K 400V Y5U вафли безопасности напряжения тока Ac керамический
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Технические характеристики изделия серии конденсатора нормы бесопасности Y1 полные
| Тип спецификация | ширина | толщина | Тангаж Pin | Руководство | Напряжение тока | емкость | материал | допуск |
| Y1-472M-Y5V | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 4700pF | Y5V | ±20% |
| Y1-332M-Y5V | φ10mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 3300pF | Y5V | ±20% |
| Y1-222M-Y5V | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 2200pF | Y5V | ±20% |
| Y1-152M-Y5V | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 1500pF | Y5V | ±20% |
| Y1-102M-Y5V | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 1000pF | Y5V | ±20% |
| Y1-472M-Y5U | φ13.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 4700pF | Y5U | ±20% |
| Y1-332M-Y5U | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 3300pF | Y5U | ±20% |
| Y1-222M-Y5U | φ10mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 2200pF | Y5U | ±20% |
| Y1-152M-Y5U | φ9mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 1500pF | Y5U | ±20% |
| Y1-102M-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 1000pF | Y5U | ±20% |
| Y1-821K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 820pF | Y5U | ±10% |
| Y1-681K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 680pF | Y5U | ±10% |
| Y1-561K-Y5U | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 560pF | Y5U | ±10% |
| Y1-471K-Y5U | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 470pF | Y5U | ±10% |
| Y1-102K-Y5P | φ11.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 1000pF | Y5P | ±10% |
| Y1-821K-Y5P | φ11mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 820pF | Y5P | ±10% |
| Y1-681K-Y5P | φ9.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 680pF | Y5P | ±10% |
| Y1-561K-Y5P | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 560pF | Y5P | ±10% |
| Y1-471K-Y5P | φ8.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 470pF | Y5P | ±10% |
| Y1-331K-Y5P | φ7.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 330pF | Y5P | ±10% |
| Y1-221K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 220pF | Y5P | ±10% |
| Y1-151K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 150pF | Y5P | ±10% |
| Y1-101K-Y5P | φ6.5mm | T4.5mm | F10mm | L3-22mm | 400V [**] c | 100pF | Y5P | ±10% |
| Y1-820K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] c | 82pF | Y5P | ±10% |
| Y1-680K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] c | 62pF | Y5P | ±10% |
| Y1-560K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] c | 56pF | Y5P | ±10% |
| Y1-470K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] c | 47pF | Y5P | ±10% |
| Y1-330K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] c | 33pF | Y5P | ±10% |
| Y1-220K-Y5P | φ7mm | T4mm | F10mm | L3-22mm | 400V [**] c | 22pF | Y5P | ±10% |
| Y1-150K-Y5P | φ6.5mm | T4mm | F10mm | L3-22mm | 400V [**] c | 15pF | Y5P | ±10% |
| Y1-100K-Y5P | φ6.5mm | T4mm | F10mm | L3-22mm | 400V [**] c | 10pF | Y5P | ±10% |
